GECC 48B

One road parallel to main road Verdun, GECC 48A is strategically located in one of the most busy and sought after places in Beirut for shopping and leisure. It is, as well, close to major destinations such as businesses, universities and schools.

A- GENERAL DESCRIPTION

  • 14 simplexes of 180 m*2 area and an underground Basement.
  • 1 parking space designated for each simplex
  • Stamped concrete & Landscaping for Ground floor.
  • Adequate water storage.
  • Fire alarm system and prevention in basement and common areas.
  • Automatic rolling shutter and barrier.
  • Building structure designed in compliance with international code of practice for earthquake resistance.

B- BUILIDING ARCHITECTURAL SPECIFICATIONS

1- Block work

  • External, double walls of 15cm thickness for the outer wall, 15cm thickness for the inner wall with 5 cm void in between. Noting that all wall exceeding 3m in length will be stiffened by vertical reinforced concrete element.

2- Plaster work

  • Plaster dabs for all apartment, Right angle and Arbasa for Reception.

3- Waterproofing

  • Membrane 4mm SBS 180g polyester for Roof Slabs and Exposed Ground Floor surfaces exposed to external weather conditions.
  • Bitumen Based Emulsion paint for all Exposed facades prior of Cladding Works.
  • Reinforced Bitumen emulsion paint for wet areas.

4- Cladding

  • High quality natural stones, Cut to size and According to Architectural Requirements and mechanically fixed to walls by mean of Galvanized Anchors.

5- External Aluminum Doors & Windows

  • Aluminum Vesta Wall profile or equivalent, colour (To be chosen).
  • Double Glazing System(6mm-8mm-6mm or As per design requirement).
  • Aluminum rolling shutters electrically motorised by Somfy Motors or equivalent.

6- Flooring

  • Parking area: Stamped Concrete.
  • Technical area: ceramic tiles UNICERAMIC or equivalent.
  • Roof area: removable concrete tiles. (Mozaic).

7- Lifts / Elevators

  • 2 passenger Elevators, Mitsulift or equivalent.

C- ELECTROMECHANICAL

1- Air conditioning

  • Centralised Ducted Air conditioning System for All Living areas (DX type System).
  • Ventilation System for Basements

2- Hot Water

  • Storage hot water tank: Locally manufactured “Chehab” 3mm thickness, insulated, ceramic from inside.

3- Plumbing

  • Polypropylene inside the apartments (in compliance with European standard).
  • UPVC pipes for sewage and drainage  (in compliance with European standard).

4- Electrical

  • European electrical wiring accessories: Vimar or Bticimo.
  • One Generators : Perkins or equivalent.
  • Electrical panel boards equipped with earth-leakage protection
  • Earthing system for all equipment and socket outlets.
  • Videophone entry control system: ELVOX or equivalent.

D- INTERIOR ARCHITECTURAL SPECIFICATIONS

1- Tiling / Floors

  • Reception area: Imported Marble 60x60cm, 2cm thickness.
  • Kitchen area: Ceramic tiles.
  • Bedrooms: Graisse Ceramic tile
  • Bathrooms: European ceramics rectified
  • Maid Bathroom: Local ceramic tiles.
  • Stairs & Landings: Imported Granite.

2- Painting

  • 2 coats of putty & 3 coats of paint ( Tinol or Sipes).for Receptions & Bedrooms.

3- Interior ceiling

  • Decorative cornices for Kitchens and Bed room
  • Gypsum False Ceiling for corridors

4- Wood works

  • Doors: Solid OAK wood for architrave & doors ( main entrance & reception). Veneered oak wood for secondary Doors.

5- Kitchen cabinets

  • Hydrofuge white color for inner side covered with lacquered veneered wood (French oak or Fraquet or nut color), covered with Granite top.

6- Sanitary fixtures and Wares

  • Sanitary Fixtures: IDEAL STANDARD or equivalent.
  • Sanitary Wares: Wall hang (Dolomitee) or equivalent.
